Connections
HDMI Video Inputs
1 x HDMI type A connector.
HDMI Video Outputs
1 x HDMI type A connector.
HDMI Audio Inputs
8 Channels embedded in SD, HD and Ultra HD.
HDMI Audio Outputs
8 Channels embedded in SD, HD and Ultra HD.
Analog Video Inputs
Component, Composite or S-Video.
Analog Video Outputs
Component, Composite or S-Video.
Analog Audio Inputs
2 Channel RCA HiFi audio in 24-bit.
Analog Audio Outputs
2 Channel RCA HiFi audio in 24-bit.
Multiple Rate Support
HDMI video connections are switchable between SD, HD and Ultra HD. Component analog video connections are switchable between SD and HD.
Computer Interface
PCI Express 4 lane, compatible with 4, 8 and 16 lane PCI Express slots.
