ADVANTAGES
Smooth printing experience
Large supplies capacity ‒ 300 meters (984’) ribbon supply or 110 meters (361’) ribbon supply on a 12.7 mm (0.5”) core
High-class thermal printing head ‒ clear print quality and
enhance durability
Optimized heat radiation design ‒ durable for large volume
printing
FEATURES
PRINT WIDTH UPTO 108 MM SUPPORTS MULTI-MEDIA TYPE
USB 2.0 FAST
TRANSMISSION SPEED
POSITION ADJUSTABLE SENSOR
LARGE SUPPLY CAPACITY
300 MTS (1”) CORE OR 100 MTS (0.5”) CORE RIBBON SUPPLY
SPECIFICATIONS
Print Method
Thermal Transfer & Direct Thermal
Resolution
8 dots/mm (203 DPI)
Memory
•16 MB Flash memory
•64 MB SDRAM
Maximum Print Width
108 mm (4.25”)
Maximum Print Speed
152mm , 6 ips
Print Length
25,400 mm (1,000″)
Interfaces
USB 2.0
Media Sensors
Transmissive gap sensor
•Black mark reflective sensor
•Ribbon end sensor
•Head open sensor
Maximum Label Length
5 ~ 25,400 mm (0.2” ~ 1000”)
Media Width
19 ~ 118 mm (0.8“ ~ 4.6“)
Media Roll Size
127 mm (5”)OD
Media Thickness
0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Media Types
Continuous, die-cut,black mark, fan-fold (outside wound),notched
Ribbon Outside Diameter
300 m long, max. OD 67 mm, 1” core (ink coated outside)
110 m long, max. OD 40 mm, 0.5” core (ink coated outside)
Ribbon Width
40 mm ~ 110 mm (1.6” ~ 4.3”)
Operating Temp
0 ~ 40°C
Storage Temp
-20 ~ 60°C
Operating Humidity
10 ~ 85%
Storage Humidity
5 ~ 90%
Media Handling
•Quick start guide
•USB cable
•Power cord
•External universal switching power supply
•Label spindle x 1, fixing tab x 2
•1” ribbon spindle x 2
•0.5” ribbon spindle x 2
1D Barcodes
Code 128UCC, Code 128 subsets A, B, C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check digit, Code
39, Code 39 with check digit, Code 93, EAN13, EAN8, UPCA, UPCE, EAN and UPC 2 (5) digits add-on, Codabar,
Postnet, MSI, MSI with check digit, PLESSEY, China post, ITF14, Code 11, TELEPEN, TELEPENN, PLANET,
Code49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
2D Barcodes
GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417
