Rode Streamer X Audio Interface and Video Capture Card
The Streamer X is a professional video capture card, audio interface and control surface integrated in one compact device that makes creating incredible content incredibly easy. It features studio-grade audio inputs...
Claim your GST Invoice with this order
Guaranteed Safe Checkout
Order in the next [totalHours] hours %M minutes to get it between and . Dispatched usually within 24 hours.
Key Features:
- Professional audio interface, video capture card and control surface integrated in one compact, easy-to-use device
- Up to 4K30 video capture and 4K60 pass-through via HDMI
- Variable Refresh Rate (VRR) support
- Neutrik® combo jack for connecting XLR microphones or instruments, with an ultra-low-noise, high-gain Revolution Preamp™ for pristine audio quality
- 3.5mm TRRS input for connecting headsets and 1/4-inch headphone output for zero-latency monitoring
- Integrated wireless receiver for connecting RØDE Series IV wireless microphones, including the Wireless GO II and Wireless ME
- Internal DSP for advanced audio processing powered by APHEX®
- Four fully customisable SMART pads for triggering sounds, voice effects and MIDI commands
- Dual USB-C interfaces for connecting to two computers or mobile devices
- Easy configuration and control via RØDE Central desktop companion app
- Compatible with free UNIFY streaming software for advanced audio routing, mixing and configuration
- Designed and made in RØDE’s precision manufacturing facilities in Sydney, Australia
Upgrade Your Stream with Pristine Audio and Flawless Video
Don't compromise your audio or your video. With up to 4K30 video capture and 4K60, zero-latency pass-through, the Streamer X delivers incredible picture quality for you and your audience. It also features our ultra-low-noise, high-gain Revolution Preamp™ for capturing pristine, studio-grade audio – no need for boosters or lifters – and with its advanced on-board DSP, you can give your voice that rich, broadcast sheen.
Professional Microphone, Headset and Wireless Connectivity
With the Streamer X, you can connect a wide array of recording devices, including an XLR microphone, instrument, headset microphone or even a RØDE Series IV wireless transmitter like the Wireless GO II or Wireless ME. You can adjust your input and output levels and switch input sources with ease thanks to the hands-on control interface, or you can even use all inputs at the same time when running our UNIFY software.
Versatile Video Streaming and Recording
Whatever your style, whatever your setup, Streamer X takes it up a level. Whether you need to capture crisp gameplay from a PC or console, connect a DSLR for brilliant real-life streams or meetings, or create a compact set-up that can be taken anywhere, Streamer X is the perfect solution.
Complete Control Over Your Content
The Streamer X offers loads of direct control over your stream, with dedicated encoders and buttons for input and output levels, mutes and input switching. It also features four fully customisable SMART pads, with up to 64 accessible via bank switching. These can be configured to trigger audio playback, add voice FX, and even send MIDI messages to your computer, allowing you to trigger any keyboard shortcut with a single press of a pad – super useful for everything from changing slides on a presentation to switching scenes in your streaming software.
Simple, Sleek and Everything You Need
Replace a complicated, multi-device set-up with a single compact device that delivers better quality with far less complexity. Out of the box, you can connect XLR microphones, headsets, instruments, and even RØDE wireless systems, as well as cameras, computers and consoles to get your stream running in minutes. With an intuitive design that offers full control whilst taking up very little precious desk space, Streamer X represents a new way to manage live streaming.
RØDE CENTRAL
RØDE Central is a companion app for the Streamer X, giving you access to advanced DSP, SMART pad customisation, granular mixer configuration, firmware updates and other device settings.
UNIFY
The Streamer X integrates seamlessly with our free UNIFY software to provide you with a hands-on interface to control the ultimate routing, mixing and streaming software.
Acoustic & Electrical Specifications
Video Input Connectors
1x HDMI Type A 2.0
Video Passthrough Output
1x HDMI Type A 2.0
Max Input Resolutions (HDMI In)
4Kp60 HDR
1440p144 HDR
1080p240 HDR
Variable Refresh Rate Support (VRR)
Yes
Max Capture Resolutions
4Kp30
1440p60
1080p120
1080p60 HDR
Audio Input Connectors
1x XLR Combo Jack (Mic/Instrument)
1x Wireless Receiver
1x Input HDMI
Audio Output Connectors
1x 3.5 TRRS Headset Jack (I/O)
1x ¼" Headphone Jack
Input Dynamic Range
113dB
Preamp Noise
-131.5dBV (A-weighted)
Frequency Range
Microphone Inputs: 20Hz-20kHz
Headphone Output: 20Hz-20kHz
Microphone Input Impedance (Ω)
4KΩ
Instrument Input Impedance (Ω)
1MΩ
Preamplifier Gain Range
0-76dB
Phantom Power
Yes
Direct Monitor
Yes
Headphone Output Power
125mW per channel
Internal Storage (GB)
2GB (SMART Pads)
Power Requirements
Via USB: 5V @
Mechanical Specifications
Weight (grams)
380g
Dimensions (millimetres)
Length: 144mm
Width: 122mm
Height: 51mm
Box Contains
1 x Streamer X
1 x USB-C to USB-C Cable
