QNAP TL-D800C (USB) 8-Bay USB 3.2 Gen2 Type-C high-capacity JBOD storage enclosure
Rs. 49,999.00
Tax included.
Guaranteed Safe Checkout
Description
Hardware Specs
TL-D800C
| JBOD Connection Interface | USB |
| Drive Bay | 8 x 3.5-inch
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives You can only use one disk type (HDD or SSD) in a RAID group. Combining different types of disk in one RAID group is not supported.
|
| Hot-swappable | |
| Form Factor | Tower |
| Host Interface | 1 x USB 3.2 Gen 2 Type-C |
| LED Indicators | HDD 1-8, Status, Link, Fan error |
| Buttons | Power switch |
| Dimensions (HxWxD) | 188.2 × 329.3 × 281.4 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) | 8.13 kg |
| Weight (Gross) | 8.4 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 250W PSU, 100 - 240V |
| Power Consumption: Operating Mode, Typical | 48.4 W
Tested with drives fully populated.
|
| Fan Mode Switch | (Auto, high, medium, low) |
| Fan | 2 x 120mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | |
| QTS / QuTS hero | |
| Windows | |
| Ubuntu | |
| Standard Warranty | 2 |
Software Specs
| Supported O.S. |
QNAP QTS / QuTS hero, Windows, Linux |
| QTS / QuTS hero |
QTS 4.4.2 / QuTS hero h4.5.0 (or newer) |
| QTS QTS drive monitoring and storage pool support |
Yes |
| QTS advanced drive features such as bad block scan, Erase,Performance Test, Seagate Ironwolf IHM |
Yes |
| RAID migrated & expanded |
Yes |
| Qtier on Enclosure |
Yes |
| Utility for other platform |
QNAP JBOD Manager |
| Windows |
Win8 or nerwer / Server2012 R2 or newer |
| Linux |
Ubuntu 18.04 |
| Device Info (Health/Bus type/PSU/Temperature/FAN) |
Yes |
| Device Temperature Warning & automatic FAN control |
Yes |
| Event Log (support Export) |
Yes |
| Enclosure located via LED & beep |
Yes |
| LCM + enclosure customizable naming |
N/A |
| SATA wiring determination |
N/A |
Package Contents
TL-D800C
Power Cord x 1
USB Type-C to Type-A connector cable x 1
Hard disk tray key x 2
USB cable clip x 1
Flat head screw x 32 (for 3.5" HDD)
Flat head screw x 24 (for 2.5" HDD)
Quick Installation Guide (QIG)
